FRONT FENDER PANEL
FRONT FENDER PANEL REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the front side marker lights.
3. Remove the front bumper.
4. Remove the front combination lights.
5. Remove in the order indicated in the table.
1 Fastener
2 Bolt A
3 Bolt B
4 Bolt C
5 Bolt D
6 Front fender panel
6. Install in the reverse order of removal.
