Power Seat
1 Slider switch knob
2 Recliner switch knob
3 Lumbar support switch knob
4 Side cover
5 Reverse cover
6 Front cover
7 Power seat switch
8 Front buckle
9 Cover
10 Seat back cover
11 Seat back trim
12 Seat warmer unit
13 Seat back pad
14 Seat back frame
15 Side air bag cover
16 Lumbar support motor
(w) RX-8 Body
