DOOR SWITCH
DOOR SWITCH REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the screw.
3. Disconnect the connector and remove the door switch.
4. Install in the reverse order of removal.
DOOR SWITCH INSPECTION
1. Remove the door switch.(See DOOR SWITCH REMOVAL/INSTALLATION .)
2. Verify that the continuity between door switch terminal and the body ground is as indicated in the table.
• If not as indicated in the table, replace the door switch.
