REAR COMBINATION LIGHT
REAR COMBINATION LIGHT REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the trunk end trim.(See TRUNK END TRIM REMOVAL/INSTALLATION .)
3. Remove the trunk side trim.(See TRUNK SIDE TRIM REMOVAL/INSTALLATION .)
4. Remove in the order indicated in the table.
1 Nut
2 Connector
3 Rear combination light
4 Socket
5 Rear turn light bulb
6 Back-up light bulb
7 Stop/taillight bulb
5. Install in the reverse order of removal.
