Mazda RX8 - Page 198

2. Remove the front side marker lights.(See FRONT SIDE MARKER LIGHT
REMOVAL/INSTALLATION .)
3. Remove the front bumper.(See FRONT BUMPER REMOVAL/INSTALLATION .)
4. Remove in the order indicated in the table.
1 Bolt A
2 Bolt B
3 Bolt C
4 Cover
5 Fastener
6 Connector
7 Front combination light
5. Install in the reverse order of removal.
6. Adjust the headlight aiming.(See HEADLIGHT AIMING )
(w) RX-8 Body
Page 198
