Turn the ignition switch to
the ON position.
B+
1I IG1
Ignition
switch
Turn the ignition switch to
the LOCK position.
1.0 or less
• Ignition switch
(See
IGNITION
SWITCH
INSPECTION
.)
• Related wiring
harness
Dimmer
switch at HI
1.0 or less
1K
High-beam
on/off
Light
switch
Turn the
ignition
switch to the
ON position.
Dimmer
switch at LO
B+
• Light switch
(See LIGHT
SWITCH
INSPECTION
.)
• Related wiring
harness
Front fog
light switch
is on.
1.0 or less
1L
Front fog light
switch ON/OFF
Front fog
light switch
Light switch
at 2nd
position
Front fog
light switch
is off.
B+
• Light switch
(See LIGHT
SWITCH
INSPECTION
.)
• Related wiring
harness
Flash-to-
pass
activated.
1.0 or less
1M Flash-to-pass
Light
switch
Turn the
ignition
switch to the
ON position.
Flash-to-
pass not
activated.
B+
• Light switch
(See LIGHT
SWITCH
INSPECTION
.)
• Related wiring
harness
