Mazda RX8 - Page 235

operation (high-
beam)
at 2nd
position
Dimmer
switch at HI
B+
• Headlight
(LH)
• Related wiring
harness
2G Power supply
DRL 15 A
fuse
Under any condition B+
• Headlight 15
A fuse
• Related wiring
harness
2H Power supply
Power
window 30
A fuse
Under any condition B+
• Power window
30 A fuse
• Related wiring
harness
(w) RX-8 Body
Page 235
