Mazda RX8 - Page 238

Car-navigation System
1
LCD unit
(See LCD UNIT REMOVAL/INSTALLATION )
2
Front tweeter
(See FRONT TWEETER REMOVAL/INSTALLATION )
(See FRONT TWEETER INSPECTION )
3
Front door speaker
(See FRONT DOOR SPEAKER REMOVAL/INSTALLATION )
(See FRONT DOOR SPEAKER INSPECTION )
4
Audio amplifier
(See AUDIO AMPLIFIER REMOVAL/INSTALLATION )
5
Audio unit
(See CENTER PANEL MODULE REMOVAL/INSTALLATION )
(See CENTER PANEL MODULE DISASSEMBLY/ASSEMBLY )
(See AUDIO UNIT DISASSEMBLY/ASSEMBLY )
6
Car-navigation unit
(See CAR-NAVIGATION UNIT REMOVAL/INSTALLATION )
7
GPS antenna
(See GPS ANTENNA REMOVAL/INSTALLATION )
8 Car-navigation control switch
(w) RX-8 Body
Page 238
