SPEAKER
FRONT DOOR SPEAKER REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the front door trim.(See FRONT DOOR TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table.
1 Screw
2
Front door speaker
(See Front Door Speaker Installation Note .)
3 Connector
4. Install in the reverse order of removal.
Front Door Speaker Installation Note
1. Remove the speaker with the wiring harness passing through the groove of the front door module.
