DTC TABLE [AUDIO SYSTEM]
Screen display
DTC
(When starting on-board diagnostic test
function)
Error message
(When error is
found)
System malfunction location
09: Er22

Base unit (peripheral circuit for tuner)
09: Er20

Power supply circuit to base unit
00: Er10

Cassette deck communication circuit system
03: Er10

CD player communication circuit system
05: Er10

CD changer (external) communication circuit
system
06: Er10

CD changer (upper module) communication
circuit system
07: Er10

MD player communication circuit system
03: Er01

CD player system
03: Er02 CHECK CD CD player system
03: Er07 CHECK CD CD player system
00: Er01

Cassette deck system
00: Er03

Cassette deck system
00: Er04 CHECK TAPE Cassette tape system
05: Er01

CD changer (external) system
05: Er07 CHECK CD CD changer (external) system
06: Er01

CD changer (upper module) system
06: Er02 CHECK CD CD changer (upper module) system
06: Er07 CHECK CD CD changer (upper module) system
07: Er01

MD player system
07: Er02 CHECK MD MD player system
07: Er07 CHECK MD MD player system
07: Er08 CHECK MD MD system
10: Er01

CD player system MP3 operation
10: Er02 CHECK CD CD player system MP3 operation
no Er

No DTCs stored
