DTC 00:ER10
DTC 00:Er10
Cassette deckbase unit communication line
DETECTION CONDITION
• Base unit detects communication error with cassette deck.
POSSIBLE CAUSE
• Malfunction of connectors between base unit and cassette deck
• Cassette deck malfunction
• Base unit malfunction
Diagnostic procedure
STEP INSPECTION ACTION
Yes Go to the next step.
1
Remove the cassette deck and verify the
connector condition (bent pins, poor female
terminal connection, trapped foreign material)
Is the connector normal?
No Repair the connector and go to the next step.
Yes Go to the next step.
2
Assemble the cassette deck to the base unit and
verify the assembly condition.
Is the assembly condition normal?
No Repair the assembly and go to the next step.
Yes
Replace the base unit and cassette deck. (See
AUDIO UNIT DISASSEMBLY/ASSEMBLY .)
3
Clear the DTC, turn the ignition switch to the
ON position and then hold for 3 s or more .
Is DTC 00: Er10 displayed?
No DTC troubleshooting completed.
