5. Install in the reverse order of removal.
FRONT DOOR LOCK ACTUATOR INSPECTION
Door Lock Actuator
1. Disconnect the front door lock actuator connector.
2. Apply battery positive voltage and connect the ground to the corresponding front door lock actuator
terminals and inspect the front door lock actuator operation.
• If not as specified, replace the front door lock actuator.
Connection
Actuator operation
B+ GND
Lock
A
(F)
B
(E)
Unlock
B
(E)
A
(F)
( )
RH
