• Disconnect the negative battery cable.
• Disconnect the instrument cluster
connector (24-pin).
• Connect the negative battery cable.
• Does the security light illuminate?
No Go to the next step.
Yes Go to the next step.
3
• Disconnect the negative battery cable.
• Ground instrument cluster terminal 2F
using a jumper wire.
• Connect the negative battery cable.
• Does the security light illuminate?
No
Replace the instrument cluster.
(See INSTRUMENT CLUSTER
REMOVAL/INSTALLATION .)
Yes
Replace the keyless control module.
(See KEYLESS CONTROL MODULE
REMOVAL/INSTALLATION .)
4
• Disconnect the negative battery cable.
• Disconnect the instrument cluster
connector.
• Connect the keyless control module
connector.
• Connect the negative battery cable.
• Turn the ignition switch to the ON
position.
• Does the security light illuminate?
No Repair the wiring harness.
