• Disconnect instrument cluster connector.
• Inspect following wiring harness between ABS (DSC)
HU/CM and instrument cluster terminals for short to
ground, short power supply, and open circuit:
ABS
 R1L (CAN_L)
 O1J (CAN_H)
DSC
 I1L (CAN_L)
 H1J (CAN_H)
• Is wiring harness normal?
No Replace wiring harness.
Yes Go to the next step.
24
INSPECT STEERING ANGLE SENSOR CONNECTOR
• Disconnect negative battery cable.
• Disconnect steering angle sensor connector.
• Is steering angle sensor connector normal?
No Replace wiring harness.
Yes
Replace steering angle
sensor, then go to Step 44.
25
INSPECT WIRING HARNESS BETWEEN STEERING ANGLE
SENSOR AND INSTRUMENT CLUSTER
• Disconnect instrument cluster connector.
• Inspect following wiring harness between steering angle
sensor and instrument cluster terminals for short to ground,
short power supply, and open circuit:
 F1L (CAN_L)
 E1J (CAN_H)
• Is wiring harness normal?
No Replace wiring harness.
Yes Go to the next step.
26
INSPECT TPMS CONTROL MODULE CONNECTOR
• Disconnect negative battery cable.
• Disconnect TPMS control module connector.
• Is TPMS control module connector normal?
No Replace wiring harness.
27
INSPECT WIRING HARNESS BETWEEN TPMS CONTROL
MODULE AND INSTRUMENT CLUSTER
Yes
Replace TPMS control
module, then go to Step 44.
