(See SUNROOF MOTOR REMOVAL/INSTALLATION .)
(See SUNROOF MOTOR INSPECTION .)
6
Front drain hose
(See FRONT DRAIN HOSE REMOVAL .)
(See FRONT DRAIN HOSE INSTALLATION .)
SUNROOF UNIT
GLASS PANEL REMOVAL/INSTALLATION
1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, then remove the glass panel.
4. Remove the weatherstrip from the glass panel.
(w) RX-8 Body
Page 53
