Assembly instructions
Pergola
8a. Connect the sub end of the light bar
on beam B2 with the female end of the
light bar on the beam C - tighten the
cap. Repeat for other 2 corners - expect
corner with the power supply.
Female end Sub end
Connect convex of female end
with concave of sub end
with concave of sub end
Sub end
Female end
8a.
8c.
8b.
8b.
Ensure power supply output is connect as
shown on the left with the ‘T’ shaped controller
connected to the power supply. Connect sub
end on beam B1 with the female end of the
controller. Tighten screw cap. Connect the
female end of beam C with the sub end of the
controller. Tighten screw cap.
Connect convex of female end
B1
C
8c. Fix the power supply on the
beam C with screws K7. Adjust the
LEDs with the remote control
QTY: 1PCSP K7 QTY: 2PCS
To Next Page
