MB Connect Line mbNET MDH816 User Manual

Page 14 of 226
Version: 3.3.5 – DR05 – 23.03.2017
Optional interfaces
WAN interface
10/100 Mbit/s full and half duplex operation, autodetection patch cable / crossover
cable
Interface 1 (COM1)
RS-232/485 (using software switchable)
Interface 2 (COM2)
depending on the device
RS-232/485 (using software switchable) or MPI/PROFIBUS - 12 Mbit/s
SIM card slots
2 pcs. SIM card reader with ejector (for mini-SIM)
Communication
Devices with analog modem (Item no.: 8810-UL, 8815-UL, 8830-UL)
Target region
240 countries
Modulation type
V.21, V.22, V22bis, V.23, V.32, V.32bis, V.34
Data compression
V.42bis, MNP5
Error correction
MNP 2-4, V.42 LAPM
Dialing method
MFV/IWV
Modem connector
RJ11 socket
FCC
Part 15 & Part 68
Devices with UMTS (3G) modem (Item no.: 8814-UL, 8819-UL, 8834-UL, 8849-UL)
Target region
Global
GSM / GPRS / EDGE
850, 900, 1800, 1900 MHz; downlink max. 296 kbps, uplink max. 236.8 kbps
HSxPA
800/850, 900, AWS 1700, 1900, 2100 MHz; downlink max. 21 Mbps, uplink max.
5.76 Mbps
Antenna connector
SMA socket
FCC
FCC ID: R17HE910
Devices with UMTS (3G) modem (Item no.: 8813-UL, 8818-UL, 8833-UL)
Target region
EMEA (Europe, the Middle East and Africa), Australia
APAC (East Asia, Southeast Asia, Australia and Oceania)
LATAM (Latin America)
GSM / GPRS / EDGE
850, 900, 1800, 1900 MHz; downlink max. 296 kbps, uplink max. 236,8 kbps
HSxPA
800/850, 900, AWS 1700, 1900, 2100 MHz; downlink max. 7.2 Mbps, uplink max.
5.76 Mbps
Devices with LTE (4G) modem (Item no.: 8850-UL-EU, 8855-UL-EU, 8858-UL-EU, 8859-UL-EU)
Target region
EMEA (Europe, the Middle East and Africa), Australia
GSM /GPRS / EDGE
850, 900, 1800, 1900 MHz; max. 236 kbps
HSxPA
850, 900, 1900, 2100 MHz; downlink max. 42 Mbps, uplink max. 5.76 Mbps
LTE
800, 900, 1800, 2100, 2600 MHz; downlink max. 100 Mbps, uplink max. 50 Mbps
Antenna connector
SMA socket
FCC
FCC ID: N7NMC7304
Devices with LTE (4G) modem - AT&T (Item no.: 8850-UL-AT&T, 8855-UL- AT&T, 8858-UL- AT&T, 8859-UL-
AT&T)
Target region
AMER (North and South America)
CDMA 1XRTT / EV-DO REV A
800 (BC0), 1900 PCS (BC1), Secondary 800 (BC10) MHz; max. 236 kbps
GSM / GPRS / EDGE
850, 900, 1800, 1900 MHz; max. 236 kbps

MB Connect Line mbNET MDH816 Specifications

General

Brand	MB Connect Line
Model	mbNET MDH816
Category	Network Router
Language	English
