7. mbl 101 E MKII Speciﬁcations

System 4-way

Frequency range 24 Hz to 40,000Hz

Impedance 4 Ohms

SPL sound pressure level 82 dB/W/m (2.83V/ 2pi)

linear max. 106 dB

Crossover frequencies 105 Hz, 600 Hz, 3500 Hz

Linkwitz-Riley, 4th order

Acoustic center 119 cm / 47“

Continuous power 320 W / 500 W

Peak power 2200 W

Subwoofer 300 mm, 12“ Aluminium

Woofer Radial TT100 (MBL)

Midrange high Radial MT50, CFRP (MBL)

Tweeter Radial HT37/E, CFRP (MBL)

Dimensions (WxHxD) 450 x 1230 x 500 mm

H (incl. cover) = 1550 mm

116 x 48 (61) x 18“

Weight 80 kg, 176 lbs

Design and speciﬁcations are subject to change without notice.
