Quick Start
Installation Guide
WARRANTY
Maxxsonics USA Inc. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics USA Inc. will, at it’s discretion, repair or replace defective products during the warranty
period. Components that prove to be defective in materials and workmanship under proper installation
and use must be returned to the original authorized Maxxsonics USA Inc. retailer from where it was
purchased. A photocopy of the original receipt must accompany the product being returned. The
costs associated with removal, re-installation and freight are not the responsibility of Maxxsonics
USA Inc. This warranty is limited to defective parts and specifi cally excludes any incidental or
consequential damages connected therewith. To view the full warranty, please visit the website.
MBQuart products are designed and engineered in the USA by
847-540-7700
www.maxxsonics.com
MBQ Discus shallow wfr QSG 01 - rev2
A Low pass fi lter will allow only
the bass frequencies to reach the
woofer making for a more natural
transition to the higher frequency
drivers. Check your amplifi er’s
manual for details.
We recommend using an
electronic subsonic fi lter. This will
help to protect the woofer from
extreme low frequency distortion.
Many amplifi ers are equipped
with this type fi lter. Check your
amplifi er’s manual for details.
This subwoofer is equipped with
quick disconnect type terminals.
Use crimp type terminals or solder
the wire directly to the terminals.
Depending on the number of woofers you intend to use,
you can confi gure the wiring to provide the best impedance
load for your system. Below are some examples. Consult
your amplifi er’s manual for recommendations.
Low Pass (LPF)
Subsonic
Confi gurations
Connections
Subwoofer specifi cationsCrossovers
Wiring
