MBQuart Discus - Product Installation - DKH 168;169;DTH 169 (Step 5); Product Installation - DKH 168;169;DTH 169 (Step 6)

6 pages

To Next Page

To Previous Page

DKH 168 / DKH 169 / DTH 169

MODEL CUTOUT DIAMETER MOUNTING DEPTH

DKH110/210 100.8mm/3.97in 55mm/2.17in

DKH113/213 130.8mm/5.15in 70mm/2.76in

DKH116/216 142.5mm/5.61in 66.6mm/2.62in

DKH168 62.6mm/2.47in

DKH169/DTH169 83.7mm/3.3in
