3-- 3
© 2012 Mobile Climate Control T-299 Rev. 08/2012
Table 3-2 Evaporator Current Draw (GEN 5)
MODEL VOLTAGE
SPEED SETTING (3) AND AMP DRAW
LOW - AMP MEDIUM - AMP HIGH - AMP
EM-1
13.5 VDC 9.7 Amp 17.9 Amp 29.5 Amp
24.5 VDC
EM-2
13.5 VDC 8.8 Amp 13.3 Amp 24.3 Amp
24.5 VDC
EM-3
13.5 VDC 16 Amp 32.2 Amp 46 Amp
24.5 VDC
EM-7
13.5 VDC 7Amp 11.5 Amp 15.9 Amp
24.5 VDC
MODEL VOLTAGE
VARIABLE SPEED CONTROL - AMP DRAW
HIGH SPEED - MAX
EM-1
12.5 VDC Fully Loaded 29.5 Amp
13.5 VDC Fully Loaded 30.1 Amp
24.5 VDC Fully Loaded 16 Amp
EM-2
12.5 VDC Fully Loaded 23 Amp
13.5 VDC Fully Loaded 24.3 Amp
24.5 VDC Fully Loaded 12 Amp
EM-3
12.5 VDC Fully Loaded 46 Amp
13.5 VDC Fully Loaded 46 Amp
24.5 VDC Fully Loaded 24 Amp
EM-7
12.5 VDC Fully Loaded 15 Amp
13.5 VDC Fully Loaded 15.9 Amp
24.5 VDC Fully Loaded 10 Amp
Table 3-3 Condenser Current Draw (GEN 5)
MODEL VOLTAGE AMP DRAW
CM-2 13.5 VDC 14.5 Amp
CM-2 With
Vector Fans
13.5 VDC 13.5 Amp
CM-3 13.5 VDC 22.5 Amp
CM-3 With
Vector Fans
13.5 VDC 20.5 Amp
CM-14 13.5 VDC 27.8 Amp
KR-2
13.5 VDC
25 VDC
14.0 Amp
10.0 Amp
KR-3
13.5 VDC
25 VDC
21.0 Amp
16.0 AMp
KR-4
13.5 VDC
25 VDC
44.0 Amps
22.0 Amps
Note: Condenser Amp Draw Increases As Static Pressure Increases
