4-- 4© 2012 Mobile Climate Control T-299 Rev. 08/2012
TXV
EVAPORATOR COIL
CONDENSER COIL
FILTER DRYER
SIGHT GLASS
RECEIVER/DRIER
SUCTION ACCESS
HPS
LPS
DISCHARGE
ACCESS
COMPRESSOR
LPS
(New Location GEN 5)
(GEN 4
Location)
D
S
1.
2.
3.
4.
5.
6.
7.
NOTE:
MICRO--CHANNEL
CONDENSER HPS IS LO-
CATED ON RECEIVER--
DRIER
HPS
Rec/Dri
1. Vacuum Pump
2. Micron Gauge
3. Manifold Gauge Set
4. Refrigerant Cylinder
5. Recovery/Recycle Machine
6. R134a High (Discharge) Side Coupler
7. R134a Low (Suction) Side Coupler
Figure 4-2 Refrigerant Service Connections (Split Systems)
