FITTING THE MULCHING PLUG TO THE MOWER (OPTIONAL)
1. Stop the engine.
2. Make sure the discharge chute and the underside of the mower are clean. If not, clean the mower.
3. Raise the ap with left hand, and using the hand-hold on the mulching plug, insert the mulching plug, with
the angled section to the mowers right, into the discharge chute. Make sure the back of the plug is sitting
on the rear axle, then lower the ap.
AU
1. Stop the engine.
2. Make sure the discharge chute and the underside of the mower are clean. If not, clean the
mower.
3. Raise the flap with left hand, and using the hand-hold on the mulching plug, insert the
mulching plug, with the angled section to the mowers right, into the discharge chute. Make
sure the back of the plug is sitting on the rear axle, then lower the flap.
Fig. 8A
Fig. 8B
FITTING THE MULCHING PLUG TO THE MOWER (OPTIONAL)
