6. INSTALLATION
The magnetic antenna must be positioned on a metal body. It should preferably be vertical and at least 30
cm away from other metal bodies.
The installation must take place in a place where the LoRaWAN ™ signal coverage is good (SF=7 optimal,
SF=12 weak).
Use the provided clip to hold the antenna connector in place, as in the pictures:
7. ORDERING CODE
Ordering Code
Description
MCF-LW06232
Serial to LoRaWAN™ interface EU863-870
MCF-LW06232-AS
Serial to LoRaWAN™ interface AS923
