McFarlane RD-4025 - Specifications and Torque Settings; Bolt Torque Specifications; Tire and Lug Torque

17
BOLT TORQUE SPECIFICTIONS
Coarse Thread Series Fine Thread Series
Nut Size
and
Threads
per Inch
Nut
Tightening
Torque
(lb.ft.)
Nut Size
and
Threads
per Inch
Nut
Tightening
Torque
(lb.ft.)
Grade C Nuts Grade C Nuts
Max. Min. Max. Min.
1/4 - 20 14.7 10 1/4 - 28 14.7 10
5/16 - 18 22.3 15.2 5/16 - 24 23.4 18.4
3/8 - 16 39 28 3/8 - 24 41 30
7/16 - 14 60 44 7/16 - 20 60 44
1/2 - 13 88 63 1/2 - 20 98 70
9/16 - 12 134 98 9/16 - 18 134 98
5/8 - 11 172 127 5/8 - 18 176 127
3/4 - 10 295 218 3/4 - 16 295 218
7/8 - 9 440 317 7/8 - 14 440 317
1 - 8 651 506 1 - 14 703 610
TIRE & LUG TORQUE SPECIFICTIONS
Tire Size
Ply
Rating
Tire
Pressure Lug Size
Lug
Tightening
Torque (lb.ft.)
Max. Min.
18.5X8.5-8 6 ply 50 psi ½ nut 85 75
7.60-15 8 ply 52 psi ½ x 1 85 75
9.5L-15 8 ply 44 psi ½ x 1 85 75
11L-15 8 ply 36 psi ½ x 1 85 75
12.5L-15 10 ply 44 psi 9/16 x 1 80 90
12.5L-15 12 ply 52 psi 9/16 x 1 80 90
12.5L-15 18 ply 72 psi 5/8 nut 85 100
12.5L-15 F ply 90 psi 5/8 nut 85 100
36x16-17.5 14 ply 75 psi 5/8 nut 85 100
