18
HI TCH FRAME
FOR RD-4000 SERIES
Key Part No. Description Notes/ Revisions
1
1
1
RD-4411
RD-4409
RD-4418
HI TCH, 4X6 (4012-4014)
HI TCH, 4X6 (4016-4030)
HI TCH, 6X6 (4035-4045)
2 RT-2107 HI NGE PI N, 1-1/ 2x9-5/ 8
3 BHY-5635 9/ 16 - 12 X 3 1/ 2 GRADE 8 BOLT
4 NLT-5612 9/ 16-12 TOP LOCK NUT
5 RT-2112 PI VOT END TURNBUCKLE, 3 7/ 8” DOM
6 RT-3145 HI TCH TURNBUCKLE - 30"
7 RT-2111 HI TCH END TURNBUCKLE, 2 EAR
8 RT-2114 TURNBUCKLE LOCK, 3"
9 BH-5028 1/ 2 X 2 3/ 4 GRADE 5 HEX BOLT
10 RT-2113 TURNBUCKLE PI N - 1 1/ 4 X 5 1/ 4
11 RD-4309 HYDRAULIC HOSE RACK CLAMP
12 BH-4420 7/ 16 X 2 HEX BOLT
13 NLT-4414 7/ 16 TOP LOCK NUT
14 LW-0025 1/ 4 LOCK WASHER
15 NH-2520 1/ 4 HEX NUT
16 PH-8860 HITCH PIN, 7/ 8 x 6 w/ # 6 BRI DGE PI N
17 RT-2416 TURNBUCKLE WRENCH, 1 1/ 4"
18 LB-1110 LIGHT PLUG STORAGE
