NOTICE
READ AND UNDERSTAND THE OPERATOR’S
MANUAL BEFORE USING.
TRANSPORT LOCKUPS AND WING LOCK
PINS MUST BE USED DURING TRANSPORT.
DO NOT RUN THE DISK GANGS TO A DEPTH
GREATER THAN 4 (FOUR) INCHES.
MAXIMUM FIELD TRAVEL SPEED IS 9 MPH.
A B C D E F G
ļ Each mark represents a 1” change in disk depth.
7XUQ ´
'HHSHU
