57567 Parts List
Part Description Qty
1 Drain Valve 1
2 Feet 4
3 Tank 1
4 Power Cord 1
5 Tension Disc 1
6 Screw ST4.2*15-F 6
7 Hose 1
8 Clamp 4
9 NPT 1/8 Two Way Connector 3
10 Screw M4*40 4
11 Cylinder Cover 1
12 O-Ring 2
13 Valve Plate 1
14 Cylinder 1
15 Paper Gasket 2
16 Screw M5*10 1
17 Screw M4*22 2
18 Flat Washer 4
19 Screw ST2.9*10-C 1
20 Muffler Top Cover 1
21 Piston 1
22 O-Ring 1
23 Muffler Bottom Cover 1
24 Connecting Rod 1
25 Ball Bearing 608-2rs 1
26 Hex Screw M6*20 3
27 Crankshaft 1
28 Flat Washer Ø6 2
29 Circlip 2
Part Description Qty
30 Bracket 1
31 Ball Bearing 6200-2rs 2
32 Gear Shaft 1
33 Gasket 1
34 Gear 1
35 Gear Box Cover 1
36 Screw M4*13 2
37 Hex Lock Nut M4 2
38 Small Gear 1
39 Motor 1
40 Handle 1
41 Hex Socket Screw ST4.2*15-F 8
42 Upper Cover 1
43 Pressure Gauge 2
44 Coupler 1
45 Regulator Assembly 1
46 Hex Socket Screw ST4.2*10-F 1
47 Safety Valve 1
48 Shock Pad 3
49 Screw M5*10 1
50 Washer Ø5 1
51 Tube 1
52 Screw M6*15 4
53 Power Switch 1
54 Bottom Cover 1
55 Ball 1
56 Spring 1
57 Pressure Switch 1
