McIntosh MPC1500 Service Manual

2
1. Unless otherwise noted, all voltages indicated on
the schematics are measured under the following
conditions:
a. AC input at rated voltage marked on rear panel.
b. All voltages are +/-10% with respect to ground. A
high impedance (10 megaohm) voltmeter must be used.
2.Unlessotherwisespecied:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH)
3. On PC board drawings, Square pad indicates:
a. Polarized Capacitors - Positive
b. Diodes - Cathode
c. Others - Pin 1
4. WARNING
Parts marked with the symbol have critical
characteristics. Use only replacement parts recom-
mended by the manufacturer.
NOTES
PERFORMANCE SPECIFICATIONS
MPC1500 - 230V Specications
Power Requirement
230V ~ 50/60Hz
6 Amps, maximum current
1380 Watts, maximum power
Output Voltage
230 Volts AC Nominal
Load Regulation
± 2.5 %
Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 7-5/8 inches (19.37cm) including feet
Depth is 22 inches (55.88cm) including the Front
Panel, Knobs and Cables
Weight
87 pounds (39.46 kg) net, 105 pounds (47.63 kg) in
shipping carton
Shipping Carton Dimensions
Width is 29-1/2 inches (74.93cm)
Depth is 29 inches (73.66cm)
Height is 17 inches (43.18cm)

McIntosh MPC1500 Specifications

General

Brand	McIntosh
Model	MPC1500
Category	Controller
Language	English
