Connect cable ① and 1 of the same color from the backrest and cushions.
.
Connect the USB cable to the interface ② on the seat base.
.
Connect remote control D with the interface ③ from the seat base.
.
Connect power supply E to the interface ④ from the seat base.
The USB port is installed on the bottom of the armrest of the sofa.
The motor cable is wrapped around the push rod behind the seat base.
STEP 3
-
02
-
NOTE：
Sofa assembly instruction 7550
B1
B2
2
3
4
USB
1
1
Seat base
Backrest
Remote control
Must be ASSEMBLED
Power adapter
1
Ｅ
Ｄ
Ｆ
Ｇ
1
2 3
4
EN
