INTRODUCTION
Thank you for buying SG1638N series function generator/counter.
Please read this manual carefully before operation and keep it well.
Suggest to use an oscilloscope to watch the waveform when operation.
Please select the real input voltage by the voltage selector
Instrument’s AC power supply should have safe GND.
Changing fuse should be fit for given request.
Each output, input port should not contact AC power supply.
Each output, input port should not contact over ±35V AC or DC power.
Output port should try to avoid long-time short circuit. (≤1min)
In order to ensure instrument’s accuracy, please avoid strong magnetoelectricity.
1. Specifications:
1.1 Main output:
Model SG1638N
Output frequency 0.2Hz～2MHz
Frequency step six-step, decimalism
Frequency adjustment ratio
Rate: 0.1～1 Range: 0.2~2
Output waves sine、square、triangle、pulse、ramp、and 50Hz sine
Output impedance 50Ω±10%
Output signal type single、VCF
VCF 0～10V
Output amplitude 20Vp-p (1MΩ) 10Vp-p (50Ω)
Output protection short circuit, resist input voltage: ±35V (1min)
Distortion of sine waves
≤100k 2%
Duty adjustment 20%～80%
DC offset ±10V (1MΩ) ±5V (50Ω)
Rising time of square wave
100ns 5Vp-p 1MHz
Attenuation accuracy ≤±3%
Effect of duty on frequency
±10%
1.2 TTL out
Model SG1638N
Output amplitude “0”:≤0.6V; “1”: ≥2.8V 600Ω
