MCQUAY Service Guide Book Appendix
78
Model M5WMY10/15KR; M5LCY10/15ER; M5LCY30/40/50/60FR
Resistance R25=20.0kΩ + 1.0% - 1.0%
T°C A (kΩ) B (kΩ) T°C A (kΩ) B (kΩ) T°C A (kΩ) B (kΩ)
-20 197.81 192.08 20 25.01 24.45 60 4.96 4.87
-19 189.53 181.16 21 23.91 23.37 61 4.79 4.70
-18 175.97 170.94 22 22.85 22.35 62 4.62 4.54
-17 166.07 161.36 23 21.85 21.37 63 4.46 4.38
-16 156.80 152.38 24 20.90 20.45 64 4.30 4.23
-15 148.10 143.96 25 20.00 19.56 65 4.16 4.08
-14 139.94 136.05 26 19.14 18.73 66 4.01 3.94
-13 132.28 128.63 27 19.32 17.93 67 3.88 3.81
-12 125.09 121.66 28 17.54 17.17 68 3.75 3.68
-11 118.34 115.12 29 16.80 16.45 69 3.62 3.56
-10 111.99 108.96 30 16.10 15.76 70 3.50 3.44
-9 106.03 103.18 31 15.43 15.10 71 3.38 3.32
-8 100.41 97.73 32 14.79 14.48 72 3.27 3.21
-7 95.14 92.61 33 14.18 13.88 73 3.16 3.11
-6 90.71 87.79 34 13.59 13.31 74 3.06 3.01
-5 85.49 83.25 35 13.04 12.77 75 2.96 2.91
-4 81.08 78.97 36 12.51 12.25 76 2.86 2.82
-3 76.93 74.94 37 12.01 11.76 77 2.77 2.72
-2 73.01 71.14 38 11.52 11.29 78 2.68 2.64
-1 69.32 67.56 39 11.06 10.84 79 2.60 2.55
0 65.84 64.17 40 10.63 10.41 80 2.51 2.47
1 62.54 60.96 41 10.21 10.00
2 59.43 57.94 42 9.81 9.61
3 56.49 55.08 43 9.42 9.24
4 53.71 52.38 44 9.06 8.88
5 51.09 49.83 45 8.71 8.54
6 48.61 47.42 46 8.37 8.21
7 46.26 45.14 47 8.05 7.90
8 44.05 42.98 48 7.75 7.60
9 41.95 40.94 49 7.46 7.31
10 39.96 39.01 50 7.18 7.04
11 38.08 37.18 51 6.91 6.78
12 36.30 35.45 52 6.65 6.53
13 34.62 33.81 53 6.65 6.53
14 33.02 32.25 54 6.65 6.53
15 31.50 30.77 55 6.41 6.29
16 30.06 29.37 56 6.18 6.06
17 28.70 28.05 57 5.95 5.84
18 27.41 26.78 58 5.74 5.43
19 26.18 25.59 59 5.14 5.05
Note: Sensor A – Outdoor air, coil and pipes (except for discharge pipe thermistor)
Sensor B – Fin
