105
Model: M5LC 010C / 015C
No Descriptions Part No No Descriptions Part No
1 Assy., Base Pan A50014051158 11 Right Panel A01014051167
2 Assy., Condenser Coil A50024064721 12 Assy., Front Panel A01014051171
3 Valve Bracket A01014051164 13 Assy. Control Panel
4 Compressor M5LC 010C A50044058195
M5LC 010C A04019019590 M5LC 015C A50044057994
M5LC 015C A04019019594 14 Assy., Valve Cover A50124051173
5 Assy., Partition A50064055063 15 Assy., Front Grille A50124056700
6 Assy., Cap Tube 16 Plastic, Handle A12014057948
M5LC 010C A50024056101 17 Rubber Grommet
M5LC 015C A50024054807 M5LC 010C A11054000272
7 Bracket, Fan Motor A01014051162 M5LC 015C A11054000271
8 Fan Motor 18 Assy., Flare Vlave 2 Ways 1/4" A50059019453
M5LC 010C A03039016104 19 Assy., Flare Valve 3 Ways 3/8"
M5LC 015C A03039015323 M5LC 010C A50059019454
9 Fan Blade A03019015339 Assy., Flare Valve 3 Ways 1/2"
10 Left Panel A01014051166 M5LC 015C A50054019452
To Next Page
