Model: M5LC 010CR / 015CR
No. Descriptions Part No No. Descriptions Part No
1
A
ssy., Base Pan
A
50014051158 11 Left Panel
A
01014051166
2 Assy., Condenser Coil 12 Right Panel A01014051167
M5LC 010CR
A
50024064721 13
A
ssy., Front Panel
A
01014051171
M5LC 015CR A50024066517 14 Assy. Control Panel
3 Valve Bracket
A
01014051164 M5LC 010CR
A
50044059033
4 Compressor M5LC 015CR A50044059034
M5LC 010CR
A
04019019590 15
A
ssy., Valve Cover
A50124051173
M5LC 015CR A04019019594 16 Assy., Front Grille
A50124056700
5
A
ssy., Partition
A
01014051165 17 Plastic, Handle
A
12014057948
6 Assy., 4 Way Valve A50024066173 18 Rubber Grommet
7 Assy., Cap Tube M5LC 010CR A11054000272
M5LC 010CR
A
50024066256 M5LC 015CR
A
11054000271
M5LC 015CR A50024066493 19 Assy., Flare Valve 2 Ways 1/4" A50059019453
8 Bracket, Fan Motor
A
01014051162 20
A
ssy., Flare Valve 3 Ways 3/8"
9 Fan Motor M5LC 010CR A50059019454
M5LC 010CR A03039016104 Assy., Flare Valve 3 Ways 1/2"
M5LC 015CR
A
03039015323 M5LC 015CR
A
50054019452
10 Fan Blade
A
03019015339 21 Sensor, Outdoor Defrost
A
50134039416
