HEATING MODE
R22 Models
(Heatpump)
Model : MWM 010GR / MLC 010CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 1.296 1.296 1.543 1.543 1.625 1.625 2.531 2.531 3.025 3.025 3.272 3.272 3.519 3.519
17
1.261 1.261 1.523 1.523 1.611 1.611 2.571 2.571 2.998 2.998 3.243 3.243 3.488 3.488
19
1.226 1.226 1.504 1.504 1.596 1.596 2.612 2.612 2.971 2.971 3.214 3.214 3.456 3.456
21 1.191 1.191 1.484 1.484 1.582 1.582 2.652 2.652 2.944 2.944 3.185 3.185 3.425 3.425
23 1.204 1.204 1.476 1.476 1.567 1.567 2.563 2.563 2.917 2.917 3.155 3.155 3.394 3.394
25
1.217 1.217 1.469 1.469 1.553 1.553 2.474 2.474 2.890 2.890 3.126 3.126 3.362 3.362
27
1.23 1.230 1.461 1.461 1.538 1.538 2.386 2.386 2.863 2.863 3.097 3.097 3.331 3.331
ID DB°C -9 -6 18
FROST REGION
-5 6 12 15
Outdoor WB°C
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.170 1.962 2.967 1.774 2.763 1.586 2.560 1.398 2.356 1.211 2.112 0.985
16 3.207 1.794 3.013 1.629 2.818 1.465 2.624 1.301 2.429 1.136 2.196 0.939
16
3.207 2.381 3.013 2.216 2.818 2.052 2.624 1.888 2.429 1.723 2.196 1.526
17
3.244 2.212 3.059 2.071 2.874 1.931 2.688 1.790 2.503 1.649 2.281 1.480
18
3.281 2.044 3.105 1.927 2.929 1.810 2.753 1.692 2.577 1.575 2.365 1.434
19 3.318 1.876 3.151 1.782 2.984 1.688 2.817 1.595 2.650 1.501 2.450 1.388
20 3.354 1.707 3.194 1.631 3.034 1.555 2.874 1.479 2.714 1.403 2.522 1.312
18 3.281 2.631 3.105 2.514 2.929 2.396 2.753 2.279 2.577 2.162 2.365 2.021
19 3.318 2.463 3.151 2.369 2.984 2.275 2.817 2.181 2.650 2.088 2.450 1.975
20 3.354 2.294 3.194 2.218 3.034 2.142 2.874 2.066 2.714 1.990 2.522 1.899
21 3.391 2.124 3.236 2.062 3.081 2.000 2.926 1.938 2.772 1.876 2.586 1.801
22
3.427 1.955 3.278 1.907 3.128 1.858 2.979 1.810 2.829 1.762 2.650 1.704
23
3.464 1.785 3.319 1.751 3.175 1.717 3.031 1.683 2.887 1.648 2.714 1.607
24
3.500 1.616 3.361 1.596 3.222 1.575 3.083 1.555 2.944 1.534 2.778 1.510
20 3.354 2.587 3.194 2.511 3.034 2.435 2.874 2.359 2.714 2.283 2.522 2.192
21 3.391 2.418 3.236 2.356 3.081 2.293 2.926 2.231 2.772 2.169 2.586 2.095
22 3.427 2.248 3.278 2.200 3.128 2.152 2.979 2.104 2.829 2.055 2.650 1.998
23 3.464 2.079 3.319 2.045 3.175 2.010 3.031 1.976 2.887 1.942 2.714 1.901
24 3.500 1.909 3.361 1.889 3.222 1.869 3.083 1.848 2.944 1.828 2.778 1.803
Outdoor DB°C
20 25 30 35 40 46
20
24
28
ID DB°C ID WB°C
30
