McQuay MWM 007G User Manual

R407C Models
(Heatpump)
Model : MWM 010GR / M4LC 010BR
COOLING MODE
27
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
1.296 1.296 1.543 1.543 1.625 1.625 2.531 2.531 3.025 3.025 3.272 3.272 3.519 3.519
17
1.261 1.261 1.523 1.523 1.611 1.611 2.571 2.571 2.998 2.998 3.243 3.243 3.488 3.488
19 1.226 1.226 1.504 1.504 1.596 1.596 2.612 2.612 2.971 2.971 3.214 3.214 3.456 3.456
21
1.191 1.191 1.484 1.484 1.582 1.582 2.652 2.652 2.944 2.944 3.185 3.185 3.425 3.425
23
1.204 1.204 1.476 1.476 1.567 1.567 2.563 2.563 2.917 2.917 3.155 3.155 3.394 3.394
25 1.217 1.217 1.469 1.469 1.553 1.553 2.474 2.474 2.890 2.890 3.126 3.126 3.362 3.362
27
1.230 1.230 1.461 1.461 1.538 1.538 2.386 2.386 2.863 2.863 3.097 3.097 3.331 3.331
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
FROST REGION
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.004 1.807 2.811 1.629 2.618 1.451 2.425 1.273 2.232 1.095 2.000 0.882
16 3.038 1.648 2.854 1.492 2.670 1.336 2.486 1.181 2.302 1.025 2.081 0.838
16
3.038 2.234 2.854 2.079 2.670 1.923 2.486 1.767 2.302 1.612 2.081 1.425
17
3.073 2.075 2.898 1.942 2.722 1.808 2.547 1.675 2.371 1.541 2.161 1.381
18
3.108 1.916 2.941 1.805 2.775 1.693 2.608 1.582 2.441 1.471 2.241 1.338
19 3.143 1.756 2.985 1.667 2.827 1.579 2.669 1.490 2.511 1.401 2.321 1.294
20 3.178 1.596 3.026 1.524 2.875 1.452 2.723 1.380 2.571 1.308 2.389 1.222
18 3.108 2.502 2.941 2.391 2.775 2.280 2.608 2.169 2.441 2.058 2.241 1.925
19 3.143 2.343 2.985 2.254 2.827 2.165 2.669 2.077 2.511 1.988 2.321 1.881
20 3.178 2.183 3.026 2.111 2.875 2.039 2.723 1.967 2.571 1.895 2.389 1.809
21 3.212 2.022 3.066 1.964 2.919 1.905 2.772 1.846 2.626 1.787 2.450 1.717
22
3.247 1.862 3.105 1.816 2.964 1.771 2.822 1.725 2.680 1.679 2.510 1.625
23
3.281 1.702 3.145 1.669 3.008 1.637 2.871 1.604 2.735 1.572 2.571 1.533
24
3.316 1.541 3.184 1.522 3.053 1.502 2.921 1.483 2.789 1.464 2.631 1.441
20 3.178 2.476 3.026 2.404 2.875 2.332 2.723 2.260 2.571 2.188 2.389 2.102
21 3.212 2.316 3.066 2.257 2.919 2.198 2.772 2.139 2.626 2.081 2.450 2.010
22 3.247 2.155 3.105 2.110 2.964 2.064 2.822 2.018 2.680 1.973 2.510 1.918
23 3.281 1.995 3.145 1.962 3.008 1.930 2.871 1.897 2.735 1.865 2.571 1.826
24 3.316 1.834 3.184 1.815 3.053 1.796 2.921 1.776 2.789 1.757 2.631 1.734
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
