R410A Models
(Heatpump)
Model : M5WM 015GR / M5LC 015CR
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.618 2.382 3.427 2.167 3.205 1.971 2.983 1.776 2.761 1.580 2.495 1.345
16 3.728 2.236 3.529 2.046 3.314 1.865 3.099 1.685 2.884 1.505 2.626 1.289
16
3.728 2.893 3.529 2.702 3.314 2.522 3.099 2.342 2.884 2.162 2.626 1.945
17
3.839 2.746 3.631 2.581 3.423 2.416 3.215 2.251 3.006 2.087 2.757 1.889
18
3.965 2.591 3.758 2.445 3.551 2.299 3.343 2.153 3.136 2.007 2.888 1.832
19 4.093 2.428 3.901 2.268 3.709 2.107 3.517 1.947 3.291 1.869 3.019 1.775
20 4.214 2.272 3.996 2.124 3.778 1.976 3.561 1.829 3.343 1.681 3.082 1.504
18 3.965 3.247 3.758 3.101 3.551 2.956 3.343 2.810 3.136 2.664 2.888 2.489
19 4.093 3.085 3.901 2.924 3.709 2.764 3.517 2.603 3.291 2.525 3.019 2.432
20 4.214 2.928 3.996 2.781 3.778 2.633 3.561 2.485 3.343 2.338 3.082 2.161
21 4.337 2.765 4.108 2.596 3.878 2.428 3.649 2.260 3.420 2.091 3.146 1.890
22
4.460 2.601 4.219 2.412 3.979 2.223 3.738 2.034 3.498 1.845 3.209 1.618
23
4.583 2.438 4.331 2.228 4.079 2.018 3.827 1.808 3.575 1.599 3.272 1.347
24
4.706 2.274 4.442 2.044 4.179 1.813 3.915 1.583 3.652 1.352 3.336 1.076
20 4.214 3.257 3.996 3.109 3.778 2.961 3.561 2.814 3.343 2.666 3.082 2.489
21 4.337 3.093 4.108 2.925 3.878 2.756 3.649 2.588 3.420 2.420 3.146 2.218
22 4.460 2.930 4.219 2.741 3.979 2.552 3.738 2.362 3.498 2.173 3.209 1.947
23 4.583 2.766 4.331 2.556 4.079 2.347 3.827 2.137 3.575 1.927 3.272 1.675
24 4.706 2.603 4.442 2.372 4.179 2.142 3.915 1.911 3.652 1.681 3.336 1.404
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.126 2.126 2.406 2.406 2.500 2.500 3.528 3.528 4.088 4.088 4.368 4.368 4.649 4.649
17
2.070 2.070 2.229 2.229 2.440 2.440 3.523 3.523 4.013 4.013 4.290 4.290 4.568 4.568
19 2.015 2.015 2.052 2.052 2.381 2.381 3.519 3.519 3.937 3.937 4.212 4.212 4.486 4.486
21
1.959 1.959 1.977 1.977 2.321 2.321 3.459 3.459 3.862 3.862 4.133 4.133 4.405 4.405
23
1.903 1.903 2.003 2.003 2.262 2.262 3.342 3.342 3.786 3.786 4.055 4.055 4.324 4.324
25 1.847 1.847 2.029 2.029 2.202 2.202 3.225 3.225 3.711 3.711 3.977 3.977 4.243 4.243
27
1.792 1.792 2.055 2.055 2.143 2.143 3.108 3.108 3.635 3.635 3.898 3.898 4.162 4.162
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
FROST REGION
