McQuay MWM09J

Performance Data MWM-J_(ii)
34
Model: MWM25J – MLC25C
Cooling Mode
Part Number: 000611101C2525
Remark:
AFR: Air flow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SHC: Sensible Heat Capacity (kW)
PI: Power Input
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 0 °C to 46°C without pressure trip.
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
21°C
6.63 4.69 1.92 6.39 4.57 2.08 6.16 4.44 2.25 5.91 4.32 2.44 5.43 4.02 2.65 5.01 3.78 2.92
24°C
6.64 5.61 1.92 6.40 5.49 2.08 6.16 5.36 2.25 5.92 5.23 2.44 5.44 4.88 2.65 5.03 4.61 2.92
27°C
6.69 6.37 1.93 6.47 6.22 2.08 6.24 6.08 2.26 6.00 5.92 2.45 5.54 5.51 2.66 5.15 5.15 2.93
30°C
6.90 6.90 1.93 6.70 6.70 2.10 6.49 6.49 2.27 6.29 6.29 2.47 5.83 5.83 2.68 5.45 5.45 2.96
24°C
7.31 4.38 1.95 7.05 4.27 2.11 6.80 4.15 2.29 6.53 4.04 2.48 6.00 3.76 2.69 5.55 3.54 2.97
27°C
7.32 5.01 1.95 7.06 4.90 2.11 6.80 4.78 2.29 6.53 4.67 2.48 6.00 4.37 2.70 5.55 4.14 2.97
30°C
7.33 6.18 1.95 7.07 6.05 2.12 6.82 5.92 2.29 6.57 5.77 2.49 6.04 5.40 2.70 5.61 5.11 2.98
33°C
7.41 7.41 1.96 7.17 7.17 2.12 6.94 6.94 2.30 6.70 6.70 2.50 6.20 6.20 2.71 5.80 5.80 2.99
27°C
8.04 4.29 1.99 7.76 4.18 2.15 7.48 4.08 2.33 7.19 3.96 2.53 6.61 3.69 2.75 6.12 3.48 3.03
30°C
8.05 5.22 1.99 7.77 5.11 2.15 7.48 4.99 2.34 7.19 4.88 2.53 6.61 4.56 2.75 6.12 4.33 3.03
33°C
8.05 6.10 1.99 7.77 5.98 2.15 7.49 5.86 2.34 7.20 5.74 2.53 6.62 5.39 2.75 6.14 5.12 3.03
36°C 8.08 6.92 1.99 7.81 6.78 2.16 7.54 6.64 2.34 7.26 6.49 2.54 6.70 6.08 2.75 6.23 5.77 3.04
21°C 6.90 4.89 1.94 6.65 4.76 2.10 6.40 4.64 2.27 6.13 4.51 2.46 5.63 4.20 2.67 5.19 3.95 2.94
24°C 6.92 5.94 1.94 6.67 5.80 2.10 6.42 5.66 2.27 6.16 5.52 2.47 5.66 5.15 2.67 5.23 4.86 2.95
27°C 7.00 6.74 1.95 6.77 6.58 2.10 6.53 6.42 2.28 6.30 6.22 2.47 5.81 5.78 2.69 5.42 5.41 2.96
30°C 7.29 7.29 1.96 7.08 7.08 2.12 6.87 6.87 2.30 6.64 6.64 2.50 6.15 6.15 2.71 5.75 5.75 3.00
24°C 7.60 4.63 1.97 7.33 4.51 2.13 7.05 4.39 2.31 6.77 4.27 2.51 6.22 3.98 2.72 5.74 3.75 3.00
27°C 7.61 5.33 1.97 7.34 5.21 2.13 7.06 5.09 2.31 6.78 4.97 2.51 6.23 4.65 2.72 5.76 4.40 3.00
30°C 7.65 6.57 1.97 7.38 6.43 2.14 7.12 6.29 2.32 6.84 6.13 2.51 6.30 5.74 2.73 5.85 5.42 3.01
33°C 7.77 7.77 1.98 7.54 7.54 2.15 7.30 7.30 2.33 7.06 7.06 2.53 6.54 6.54 2.75 6.11 6.11 3.03
27°C 8.35 4.53 2.01 8.05 4.42 2.17 7.75 4.31 2.36 7.45 4.20 2.56 6.84 3.91 2.77 6.33 3.69 3.05
30°C 8.36 5.56 2.01 8.06 5.44 2.18 7.76 5.32 2.36 7.45 5.20 2.56 6.85 4.87 2.77 6.34 4.62 3.05
33°C 8.37 6.51 2.01 8.08 6.39 2.18 7.79 6.26 2.36 7.48 6.13 2.56 6.88 5.75 2.78 6.38 5.46 3.06
36°C
8.42 7.36 2.01 8.15 7.22 2.18 7.87 7.07 2.37 7.58 6.91 2.57 6.99 6.47 2.79 6.52 6.10 3.07
21°C
7.15 5.10 1.96 6.89 4.97 2.11 6.63 4.84 2.29 6.35 4.71 2.48 5.82 4.38 2.69 5.37 4.13 2.97
24°C
7.19 6.20 1.96 6.93 6.05 2.12 6.67 5.91 2.29 6.40 5.75 2.49 5.88 5.37 2.70 5.43 5.06 2.97
27°C
7.31 7.11 1.96 7.07 6.92 2.12 6.83 6.73 2.30 6.58 6.52 2.50 6.08 6.04 2.71 5.67 5.64 2.99
30°C
7.67 7.67 1.98 7.45 7.45 2.15 7.22 7.22 2.33 6.98 6.98 2.53 6.46 6.46 2.74 6.04 6.04 3.03
24°C
7.87 4.90 1.99 7.59 4.77 2.15 7.30 4.65 2.33 7.00 4.53 2.53 6.43 4.22 2.74 5.93 3.98 3.02
27°C
7.90 5.66 1.99 7.61 5.53 2.15 7.33 5.40 2.33 7.03 5.27 2.53 6.45 4.93 2.74 5.97 4.67 3.02
30°C
7.96 6.97 1.99 7.68 6.82 2.16 7.40 6.66 2.34 7.12 6.50 2.54 6.56 6.07 2.75 6.09 5.72 3.03
33°C
8.13 8.13 2.00 7.89 7.89 2.17 7.65 7.65 2.35 7.40 7.40 2.56 6.85 6.85 2.78 6.41 6.41 3.07
27°C
8.64 4.79 2.03 8.33 4.68 2.19 8.02 4.57 2.38 7.70 4.45 2.58 7.07 4.15 2.80 6.53 3.92 3.08
30°C
8.66 5.90 2.03 8.35 5.79 2.19 8.03 5.67 2.38 7.71
5.54 2.58 7.08 5.18
2.80 6.55 4.92 3.08
33°C
8.69 6.92 2.03 8.39 6.80 2.20 8.08 6.66 2.38 7.76 6.51 2.58 7.14 6.10 2.80 6.61 5.79 3.09
36°C
8.76 7.81 2.03 8.49 7.67 2.20 8.20 7.50 2.39 7.90 7.32 2.59 7.30 6.82 2.82 6.81 6.42 3.11
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
474
16°C
19°C
22°C
537
16°C
19°C
22°C
646
16°C
19°C
22°C
