McQuay MWM09J

46
MWM-J_(ii) Performance Data
Model: M5WM25J - M5LC25CJ
Cooling Mode
Remark:
AFR:
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SHC: Sensible Heat Capacity (kW)
PI: Power Input
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 0 °C to 46°C without pressure trip.
Part Number : 0651101C2525
TC PI TC PI TC PI TC PI TC PI TC PI
AFR
(CFM)
EDB
SHC
19°C
SHC
25°C
SHC
30°C
SHC
35°C
SHC
40°C
SHC
5.67 1.42 5.47 1.54 5.26 1.66 5.05 1.80 4.64 1.96 4.28 2.16
21°C
3.96 3.85 3.75 3.64 3.39 3.19
5.67 1.42 5.47 1.54 5.27 1.66 5.06 1.81 4.65 1.96 4.30 2.16
24°C
4.74 4.63 4.52 4.41 4.12 3.89
5.72 1.42 5.53 1.54 5.33 1.67 5.13 1.81 4.74 1.96 4.41 2.17
27°C
5.37 5.25 5.13 4.99 4.65 4.36
5.90 1.43 5.73 1.55 5.55 1.68 5.37 1.82 4.98 1.98 4.66 2.19
30°C
5.90 5.73 5.55 5.37 4.98 4.66
6.25 1.44 6.03 1.56 5.81 1.
69 5.58 1.84 5.13 1.99 4.74 2.20
24°C
3.69 3.60 3.50 3.41 3.17 2.99
6.26 1.44 6.03 1.56 5.81 1.69 5.58 1.84 5.13 1.99 4.75 2.20
27°C
4.23 4.13 4.04 3.94 3.68 3.49
6.26 1.44 6.05 1.56 5.83 1.69 5.61 1.84 5.17 1.99 4.79 2.20
30°C
5.22 5.10 4.99 4.87 4.56 4.31
6.34 1.45 6.13 1.57 5.93 1.70 5.73 1.85 5.30 2.00 4.96 2.21
33°C
6.34 6.13 5.93 5.73 5.30 4.96
6.88 1.47 6.64 1.59 6.40 1.73 6.15 1.87 5.65 2.03 5.23 2.24
27°C
3.62 3.53 3.44 3.34 3.12 2.94
6.88 1.47 6.64 1.59 6.40 1.73 6.15 1.87 5.65 2.03 5.
23 2.24
30°C
4.41 4.31 4.21 4.11 3.85 3.65
6.88 1.47 6.64 1.59 6.40 1.73 6.15 1.87 5.66 2.03 5.25 2.24
33°C
5.15 5.05 4.95 4.85 4.55 4.32
6.91 1.47 6.68 1.59 6.45 1.73 6.21 1.88 5.73 2.04 5.33 2.24
36°C
5.83 5.72 5.60 5.48 5.13 4.87
5.90 1.43 5.68 1.55 5.47 1.68 5.24 1.82 4.81 1.97 4.44 2.18
21°C
4.13 4.02 3.91 3.80 3.54 3.33
5.91 1.43 5.70 1.55 5.49 1.68 5.27 1.82 4.84 1.98 4.47 2.18
24°C
5.01 4.89 4.77 4.65 4.34 4.10
5.98 1.44 5.78 1.56 5.58 1.69 5.38 1.83 4.97 1.99 4.63 2.19
27°C
5.69 5.56 5.
41 5.25 4.88 4.56
6.23 1.45 6.05 1.57 5.87 1.70 5.68 1.85 5.26 2.01 4.92 2.21
30°C
6.23 6.05 5.87 5.68 5.26 4.92
6.50 1.46 6.26 1.58 6.03 1.71 5.79 1.85 5.31 2.01 4.91 2.21
24°C
3.90 3.81 3.71 3.60 3.36 3.17
6.51 1.46 6.27 1.58 6.04 1.71 5.80 1.85 5.33 2.01 4.92 2.22
27°C
4.50 4.40 4.30 4.19 3.92 3.71
6.54 1.46 6.31 1.58 6.08 1.71 5.85 1.86 5.39 2.01 5.00 2.22
30°C
5.55 5.43 5.30 5.17 4.84 4.57
6.65 1.46 6.44 1.59 6.24 1.72 6.03 1.87 5.59 2.03 5.22 2.24
33°C
6.65 6.44 6.24 6.03 5.59 5.22
7.14 1.
48 6.89 1.61 6.63 1.74 6.37 1.89 5.85 2.05 5.41 2.26
27°C
3.82 3.73 3.64 3.54 3.30 3.11
7.15 1.48 6.89 1.61 6.64 1.74 6.37 1.89 5.86 2.05 5.42 2.26
30°C
4.69 4.59 4.49 4.39 4.11 3.90
7.16 1.48 6.91 1.61 6.66 1.74 6.39 1.89 5.88 2.05 5.45 2.26
33°C
5.49 5.39 5.28 5.17 4.85 4.60
7.20 1.49 6.97 1.61 6.73 1.75 6.48 1.90 5.98 2.06 5.58 2.27
36°C
6.21 6.09 5.97 5.83 5.45 5.15
6.11 1.45 5.89 1.56 5.66 1.69 5.43 1.83 4.98 1.99 4.59 2.19
21°C
4.31 4.20 4.09 3.97 3.70 3.48
6.15 1.45 5.92 1.57 5.70 1.70 5.
47 1.84 5.02 1.99 4.64 2.20
24°C
5.23 5.11 4.98 4.85 4.53 4.27
6.25 1.45 6.04 1.57 5.84 1.70 5.63 1.85 5.20 2.01 4.85 2.21
27°C
5.99 5.84 5.68 5.50 5.10 4.76
6.56 1.46 6.37 1.59 6.17 1.72 5.97 1.87 5.53 2.03 5.16 2.24
30°C
6.
56 6.37 6.17 5.97 5.53 5.16
6.73 1.47 6.49 1.59 6.24 1.72 5.99 1.87 5.49 2.03 5.07 2.23
24°C
4.13 4.03 3.92 3.82 3.56 3.36
6.75 1.47 6.51 1.59 6.26 1.72 6.01 1.87 5.52 2.03 5.10 2.23
27°C
4.78 4.67 4.56 4.45 4.16 3.93
6.81 1.47 6.56 1.59 6.33 1.73 6.09 1.87 5.60 2.03 5.20 2.
24
30°C
5.88 5.75 5.62 5.48 5.12 4.82
6.95 1.48 6.75 1.60 6.54 1.74 6.33 1.89 5.86 2.05 5.48 2.27
33°C
6.95 6.75 6.54 6.33 5.86 5.48
7.38 1.50 7.12 1.62 6.85 1.76 6.58 1.91 6.04 2.07 5.58 2.28
27°C
4.04 3.95 3.85 3.75 3.50 3.30
7.40 1.50 7.14 1.62 6.87 1.76 6.59 1.91 6.06 2.07 5.60 2.28
30°C
4.98 4.89 4.78 4.67 4.37 4.15
7.43 1.50 7.17 1.62 6.91 1.76 6.63 1.91 6.10 2.07 5.65 2.28
33°C
5.84 5.73 5.61 5.49 5.15 4.88
7.49 1.50 7.26 1.63 7.01 1.77 6.75 1.92 6.24 2.08 5.82 2.30
36°C
6.59 6.47 6.33 6.
17 5.76 5.42
6.11 1.46 5.90 1.57 5.68 1.70 5.46 1.85 5.02 2.01 4.63 2.24
21°C
4.34 4.24 4.13 4.02 3.75 3.53
6.13 1.46 5.91 1.57 5.70 1.70 5.48 1.85 5.04 2.01 4.67 2.24
24°C
5.31 5.19 5.08 4.96 4.64 4.38
6.23 1.46 6.04 1.58 5.85 1.71 5.65 1.86 5.24 2.03 4.89 2.25
27°C
6.09 5.93 5.78 5.61 5.24 4.89
6.57 1.48 6.39 1.59 6.20 1.73 6.01 1.88 5.57 2.05 5.22 2.28
30°C
6.57 6.39 6.20 6.01 5.57 5.22
6.73 1.48 6.49 1.60 6.26 1.73 6.02 1.88 5.54 2.04 5.12 2.27
24°C
4.16 4.06 3.97 3.87 3.61 3.41
6.75 1.48 6.
51 1.60 6.28 1.73 6.04 1.88 5.55 2.05 5.14 2.27
27°C
4.83 4.73 4.63 4.53 4.24 4.03
6.78 1.49 6.55 1.60 6.33 1.73 6.10 1.88 5.63 2.05 5.25 2.28
30°C
6.00 5.87 5.75 5.61 5.24 4.94
6.96 1.49 6.76 1.61 6.57 1.74 6.37 1.90 5.92 2.07 5.55 2.30
33°C
6.96 6.76 6.57 6.37 5.92 5.55
7.39 1.51 7.14 1.63 6.89 1.76 6.63 1.91 6.10 2.08 5.66 2.31
27°C
4.08 3.99 3.90 3.80 3.55 3.36
7.41 1.51 7.15 1.63 6.90 1.76 6.64 1.91 6.12 2.08 5.67 2.31
30°C
5.05 4.95 4.84 4.74 4.45 4.23
7.43 1.51 7.17 1.63 6.92 1.76 6.66 1.
91 6.14 2.08 5.71 2.31
33°C
5.95 5.84 5.74 5.63 5.29 5.02
7.50 1.52 7.26 1.63 7.02 1.77 6.80 1.92 6.29 2.09 5.89 2.32
36°C
6.74 6.61 6.47 6.31 5.90 5.57
46°C
474
537
614
641
EWB
16°C
19°C
22°C
16°C
19°C
22°C
16°C
19°C
22°C
16°C
19°C
22°C
Outdoor temperature
Air flow rate (CFM)
