56
MWM-J_(ii) Outline & Dimension
Indoor Unit
Model: M(5)WM20/25J/JR
Note: Dimension in mm
Outdoor Unit
Model: M(5)LC20/25CJ/CRJ
Note : Dimension in mm
For M5LC / MLC25C/CR
MODEL ABCDEFGH I JKLMNOPQRST
M(5)LC20CJ/CRJ
855 628 328 508 181 44 93 149 101 113 603 126 164 17 49 32 3 23 73 75
M(5)LC25CJ/CRJ
855 730 328 513 182 44 93 149 101 113 603 126 164 17 47 32 3 23 73 75
Note: Dimension in mm
