MEC – Energietechnik GmbH INSTRUCTION MANUAL Joe-100IM
Rev.2.0 – 18/04/2014 Page 2 of 4 www.mec-energietechnik.com
2. General Information
This microprocessor based waterproof Lead Acid Battery Charger was especially developed for the outdoor use and for situations
where water may be present. It can be used to charge any lead-based battery – including GEL, AGM, WET and CA. With the 5-
step charging program the battery will be charged safely in a fully automatic mode. The output of the charger is electronically
protected against short circuit, reverse polarity connection. The charger is able to recover deep-discharged batteries.
Coloured LEDs on the top case are used to indicate charging status, errors, and selected mode of charging. Additional it includes
a power supply mode.
The chosen battery type could be changed on the control panel. The previously selected mode will be saved as standard setting.
The integrated metal hook allows fixing the charger in different ways.
3. Special Features
Convection cooled IP68 housing
Short circuit and reverse polarity protection
LED’s to indicate operation and charging status
5-Step charging technology with automatic restart
Selectable battery type (Gel, AGM, Wet or CA) and power supply mode
Battery temperature sensor
Automatic Shut-off at too high temperature
Indicating a non-chargeable (‘dead battery’) condition
4. Product Figure
1 DC cable 4 Yellow Charge-LED 7 Press Button 10 Wall brackets
2 Green Power-LED 5 Green Full-LED 8 AC cable
3 Red Error-LED 6 Battery type-LED 9 Extractable hook
