7. Errors and Troubleshooting
Table 1: General Error:
Error description
Solution
No LED is lighting or blinking after connecting to mains supply
Check if charger is connected to mains supply
Check function of mains supply
Red Power-LED is on, charger is connected to battery and the
charging process does not start
connection to battery
Check if battery is damaged or deeply discharged
Error-LED blinking (N x blinking / 2 sec pause)
Please see the table below for error description
Table 2: Error-LED blinking signals
Blinking signal
Error description
1 x
Battery damaged
2 x
Battery voltage is too high or wrong battery connected
5 x
Charger temperature is too high to start charging
8 x
Charging cable was disconnected from battery while charging
8. Technical Data
Version
12V 20A
24V 10A
48V 6A
MEC Art.- no.
Single Profile
Multi-Profile
161-06203-470
161-06203-570
161-12103-470
161-12103-570
161-24602-470
161-24602-570
Charge Char-
acteristic
Single Profile
Multi-Profile
5-Step charge profile with temperature compensation
Four 5-Step charge profile with temperature compensation + power supply mode
Input
100-240VAC 50-60Hz
AC-cable
1.5m ±0.1m CEE 7/7
Charging Voltage nom.
12VDC
24VDC
48VDC
Charging Current max.
20A
10A
6A
Output Power max.
310W
310W
340W
Start Charging Voltage
2V
4V
8V
Restart Charging Voltage
12.8V
25.6V
51.2V
Back Current
<1mA
Efficiency
>87% @ 230VAC
DC-cable
Lenght: 1.2m ±0.1m / ringterminals Ø12mm
Displays
Single-Profile
Multi-Profile
4 LED
8 LED
Cooling
Performance-related fan
Operating Temperature Range
0°C…40°C
Device Protection
Over temperature, Reverse polarity, Short circuit, Over load
Temperature Sensor
Internal and external inside DC-cable
Certification
CE
Enclosure
Painted metal housing
Protection Class
I
IP-Code
IP20
Dimensions and Weight
235 x 158 x 66mm / ~2.3kg
9. Disposal information
It is prohibited to dispose the charger into the house- and residual waste removal (WEEE-Guideline
2002/96/EG und EAG-VO) , it must be disposed at the according collection points. For the protection of our
environment please inform yourself at your communal adminstrative agency about your nearest disposal
point.
The charger equates to the RoHS-directive 2002/95/EG, for the restriction of the use of certain hazardous
substances in electrical and electronic equipment.
10. Exclusion of warranty and liability
 MEC-Energietechnik GmbH guarantees replacement or repair of chargers that are recognized as defective under common envi-
ronmental conditions. The validation of the warranty time starts with the delivery date from the manufacturer. MEC-Energietechnik
GmbH is limiting the free guaranteeing to working hours and spare parts only.
 For damages caused by non-observance of the operating instructions, inappropriate start up or handling as well as reconstructions
and modifications of the device, the warranty claim expires and MEC-Energietechnik GmbH assumes no liability for consequential
damage to property or persons!
 Repair work must only be accomplished by authorized companies or professional staff!
Subject to technical modifications. We assume no liability for misprints.
