Chapter 4 : TECHNICAL SPECIFICATIONS
MECHANISM TECHICAL DESCRIPTION
01 Channel Dual, isolated between channels
02 Pulse Amplitude Adjustable 0-80mA, Max output 80mA peak to peak
(15.8mA rms) into 500ohm load each channel.
03 Output Voltage Adjustable 0-40V, Max output 40V peak to peak
(7.9V rms) into 500ohm load each channel.
04 Wave Form Asymmetrical Bi-Phasic Square Pulse
05 Power supply One 9 Volt Battery, type 6F22
06 Size 95(H) x 65(W) x 23.5(T) mm
07 Weight 115 grams (battery included)
08 Pulse Rate Adjustable, from 2 Hz to 150 Hz
09 Pulse Width Adjustable, from 30µs to 260µs
10 Burst Mode Bursts occur twice per second. The pulse width is
(B Mode)
11 Modulation Pulse rate is automatically varied in a cyclic pattern
over a nominal 10 second interval (in max 150Hz).
Pulse rate decreases linearly, over a period of 4 seconds,
from the control setting value to a value which is 40%
less. The lower pulse rate will continue for 1 second and
then the pulse rate increases linearly over a period of 4
seconds to the original value. This will continue for 1
second and the cycle is then repeated
12 Operating Temperature : 0°~40°C
Condition Relative Humidity : 30%~75%
Atmosphere Pressure : 700Hpa~1060Hpa
13 Remark There may be up to a +/- 5% tolerance of pulse width
and pulse rate and +/- 20% tolerance of amplitude
& voltage.
