MediaKind M2 - Page 2

SDI monitor output
External
synch input
SDI output
4
3 21
0 1
0 1
4x SDI output + Synch /
SDI monitor out
(Option)
2x 25GbE SFP28*
(Option, Slot 1 only)
MK.IO Beam Contribution & Distribution on M2 - Quick Start Guide - S17151
Slot 0/1
4x SDI/ASI + Genlock
(Option)
Ext. sync input
2 31 4
Ext. sync input
3 24 1
8 x SDI/ASI
(Option)
1
3 5
7
Ext. sync input
2 4 6 8
1357
Ext. sync input
2468
M2 Back Panel

4x 1GbE input
(Option)
2
30 1
1 03 2
2x 10GbE SFP+ input*
(Option)
01




4 x ASI input
(Option)
4 x Satellite Demod
(Option)
Satellite Modulator
(Option - Slot #3 only)
Monitor
output
Main
output
10 MHz
in/out
1 2 3 4
4 3 2 1
4 3 2 1
1 2 3 4




Slot 2/3
Dual Power Supplies
Hot Swappable
(Primary)
BMC Management / Input / Output
(4x1 GbE Base-T)

Slot #0
Slot #1
Slot #2
Slot #3
VGA + USB
HDMI
(Not supported)
Serial (Not supported)
11
* Class 1 laser product
Dual Common Interface
(Option)



