I‐3.HardwareOverview







A.  LAN1portwithPoweroverEthernet(PassivePoE‐IN).
B.  LAN2portwithPoweroverEthernet(PassivePoE‐OUT).
C.  SMAconnectorforoptionalexternalantenna.
D.  ResetButton.
E.  SwitchtheLAN2(PassivePoE‐OUT)On/Off.(Default:Off,TurnRight)

I‐4.LEDStatus

LED Behavior
Power
Blue
Theaccesspointison.
Off Theaccesspointisoff.
LAN1&2
Blue
LANportisconnected.
Flashing Activity(transferringandreceiving)
Off LANportisunconnected.
Wireless
(Clientmode
only)
Blue
RSSISignalStrength:
Excellent:4LEDsbright
Good:3LEDsbright
Medium:2LEDsbright
Bad:1LEDbright
Off Wirelessclientmodedisabled.
ALAN1(PoE‐IN)
BLAN2(PoE‐OUT)
EPoE‐OUTOn/Off
CSMA
CSMA
DResetButton
