GB
33
Application
MEDISANA TDP offers you four therapy modes and 100 preset programs,
whose parameters are provided in the tables beginning on page 15. In addition,
you can defi ne yourself two programs in TENS mode and in one program in
EMS mode (see page 35).
Mode Therapy Programs
TENS Pain therapy P-01 – P-10,
U-01 – U-02
EMS Muscle building P-01 – P-77, U-01
Deep TENS Deep pain treatment P-01 – P-05
Acupuncture Pain treatment, mobilisation P-01 – P-08
• Briefl y press the button “M” to switch to the next therapy mode. The se-
lected mode
blinks on the left edge of the display panel.
• Select the program >by briefl y pressing the button “P”. Hold the but-
ton down to increase the program number faster.
The recommended treatment points are shown on the fi gure for each pro-
gram. You can fi nd examples of electrode positions on page 38.
The device can generate different current forms for the corresponding thera-
pies. They are classifi ed into biphasic and mono-phasic pulses. With bipha-
sic pulses, the current circulates between the electrodes. With mono-phasic
pulses, the current only fl ows in one direction.
Mono-phasic is only used to stimulate muscles at low frequen-
cies (up to 40 Hz).
Bi-phasic short is preferably used at high frequencies to relief pain.
The positive (rectangular upward curve) and nega-
tive (rectangular downward curve) part follow di-
rectly after one another without interruption.
Bi-phasic long is used at high frequencies (starting at 60 Hz) both
for pain relief and also for muscle stimulation at low
frequencies (2 to 40 Hz). The positive and negative
parts of the pulse are separated from one another
by span width.
• Briefl y pressing the button “Memory” switches to the next pulse form. The
selected pulse form appears on the display panel as a symbol .
Select the
therapy mode
and program
Select the pulse
form
