TENS-Schmerztherapiegerät TDD
7
4
5
6
3
1
2
8
9
0
Display:
1
Therapy time setting
2
Intensity channel 1
3
Operation mode setting/program
selection
4
Pulse width in µsec
5
Frequency in Hz
6
Connection socket channel 1
7
Connection socket channel 2
8
Display current selection
9
Intensity channel 2
0
Battery display
GB
Keys:
A Timer = therapy time setting
B Wave = current selection
C Ch1 Intensity = increase intensity, channel 1
D Ch1 Intensity = reduce intensity, channel 1
E Frequency = frequency setting
F On/Off = on/off key
G P. Width = pulse width setting
H Ch2 Intensity = increase intensity, channel 2
J Ch2 Intensity = reduce intensity, channel 2
K Mode = operation mode setting/program
selection
Display:
1
Therapiezeit-Einstellung
2
Intensität Kanal 1
3
Betriebsmodus-Anzeige/Programmwahl
4
Impulsbreite in µsec
5
Frequenz in Hz
6
Anschlussbuchse Kanal 1
7
Anschlussbuchse Kanal 2
8
Stromformanzeige
9
Intensität Kanal 2
0
Batterieanzeige
D
Tasten:
A Timer = Therapiezeit-Einstellung
B Wave = Stromform-Auswahl
C Ch1 Intensity = höher, Kanal 1
D Ch1 Intensity = Intensität verringern, Kanal 1
E Frequency = Frequenzeinstellung
F On/Off = Ein/Aus-Taste
G P. Width = Impulsweiten-Einstellung
H Ch2 Intensity = Intensität höher, Kanal 2
J Ch2 Intensity = Intensität verringern, Kanal 2
K Mode = Betriebsmodus-Einstellung/Programmwahl
A
B
C
D
E
F
G
H
I
K
