26
3 Operating
GB
You find more examples for application in the TENS therapy booklet or other
specialized text books.
programs 1-3
Open the key cover and press the key ON/OFF. On the LCD display, the
device's factory setting appears:
Frequency 2Hz, pulse width 50 µsec, pulse form biphasic and operation modus
constant, timer is not activated.
The marking CH1
2
for channel 1 CH2
9
for channel 2 also appear. For
selecting the therapy program, press the key M (K), until the desired therapy
program is displayed.
CAUTION
The programs 1-3 start as soon as you have selected
them.
For therapy, you increase the intensity with the key C (left cable connection) or
H (right cable connection). Press the key repeatedly, until you feel that the device
delivers current.
You can read the intensity of the set current off the height of the bar above
CH 1. If you have set the intensity too high, reduce it with the key D or J. In
the course of the programm, always change the intensity when the current
strength becomes unpleasant or the tingling lessens.
After the end of the therapy time (program 1-3 automatically preset to 30
minutes each), the device switches off automatically
Switch on the device with the key ON/OFF. The device is now set to the
factory setting:
Frequency 2Hz, pulse width 50 µsec, pulse form bi-phasic and operation mode
constant, timer not activated.
The designations CH1
2
for channel 1 and CH2
9
for channel 2 are shown
this way as well. Set the parameters exactly according to the instructions of
your doctor and adjust the intensity with the keys C, D and H, J.
If you have not set the therapy time (A/
1
), make sure not to have the device
switched on longer than 30 minutes.
If the timer is set, the device switches off automatically after the preset time.
Tesions in the neck
and shoulder area
3.3
Therapy with a
preset program
3.4
Therapy according
to individual
presets
GA_TDD_10spr.qxd 06.12.2005 8:05 Uhr Seite 26
