34
3 Operating
GB
Available functions of the various modes - overall view:
Modus Timer (A) Wave (B) Frequency (E) P.Width (G)
CONST Yes Yes Yes Yes
BURST Yes Yes No Yes
MODUL I Yes Yes No Yes
MODUL II Yes Yes Yes No
PROG A Yes Yes Yes Yes
PROG 1 No No No No
PROG 2 No No No No
PROG 3 No No No No
CAUTION
The subjective feeling of current can be changed through
alternating frequencies, pulse widths or current selections.
Adjust the intensity (keys C, D and H, J), as soon as you feel
the application to be un- pleasant or the pleasant tingling
cannot be felt for a longer period of time.
Therapy time
At the right side of the clock symbol, the remaining therapy time is given in
minutes. The display changes by pressing the key A from no indication (i.e. you
fix the therapy time without indication in the display) to 20 min to 40 min and
back. At the moment the intensity in a channel is increased, the therapy starts
(Caution except for the programs 1 -3, also see "K operation mode/program
selection") and the time is counted down and shown. You can immediately
stop each therapy with the key F.
Intensity channel
By pressing the key C, horizontal lines appear above this writing, showing the
set intensity. No bar indicates that no current is activated (Caution except for
the programs 1 -3, also see "K operation mode/program selection NOTE"). If
the bars are visible up to the upper display edge, the device delivers the maximum
current, it is set to maximum intensity.
Operation mode
In this indication part, the operation modes are displayed: CONST, BURST,
Modul I or MODUL II, PROG A, 1, 2 or 3. For more detailed description of the
operation modes see "K operation mode/program selection".
3
2
1
3.6
Description of
the symbols in
the display
GA_TDD_10spr.qxd 06.12.2005 8:05 Uhr Seite 34
