Universal Energy Meter MEg40
+
Menu
Electricity meter
Monitor
Interval
display
Cycle
type
Higher
resolution
5s
10s
15s
20s
30s
40s
50s
60s
consumption
+delivery
Consumption No
Delivery
Yes
Measuring instrument Checking the connection
Recorder Maximum values of currents
Parameters of display
Paramete
rs of voltage Parameters of current Instrument
measurement (password
) measurement (password) parameters
Type Interval Manner
Quantity
Phase
Feeder
Value
Value in %
200ms
400ms
800ms
1,6s
3,2s
6,4s
12,8s
Level Voltage Unom
LV
MV
230V
MVL
3kV,6kV,10kV
Phase
Phase-to-phase
HV
20kV,22kV,35kV
110kV,220kV
400kV
I prim I sec
1A,5A,S1,S2,S3
Serial number
Version of FW
Memory capacity
Date and time
1A,5A,10A,12.5A
15A,20A,25A,30A
40A,50A,60A,75A
100A,125A,150A
200A,250A,300A
400A,500A,600A
750A.1000A,1250A
1500A,2000A,User
Recorder
State: recording in action
Recording since: dd:mm:yy
Memory: circular/linear
Interval of recording: mm.ss
Maximum values of currents
Instantaneous
values
I1 nnnA
Maximum values Maximum of feeders
I1+I2+I3 vvvA
Time: hh:mm
Date: dd:mm:rr
I2 nnnA
I3 nnnA
I1 mmmA
I2 mmmA
I3 mmmA
Connection of voltage
Sequence of phases
Connection of currents
Assignation of phases
Checking the connection
